BFT GIUNO ULTRA BT A50 Hydraulic Swing Gate Motor

Description

BFT GIUNO ULTRA BT A50 Hydraulic Swing Gate Motor in UAE

BFT GIUNO ULTRA BT A50 Hydraulic Swing Gate Motor:

• GIUNO ULTRA BT A50
• Refence P935106 00001
• Part number 2600551
• Hydraulic operator with 24 V for hinged wings up to 5 m.
• 800 kg in weight and use very intensive. Manoeuvre time 20 s.

Main features:

• Control unit with display: for easy scenario programming.
• U-Link: full interconnectivity with other devices via Bluetooth, RS-485, TCP/IP.
• New magnetic limit switch: together with D-Track technology,
• offers extreme precision of maneuver and positioning.
• Double sensor system to define in detail end of the maneuver slowdowns.
• High reliability against dust, water and ice.
• Selectable block system: the operators can be converted to reversible,
• with opening block, closing block or double block.
• All this by simply turning a key.

Technologies:

• The new coding system for direct cloning
• of remote controls Based on microprocessor technology,
• this system allows the cloning of any MITTO remote control
• in a MITTO REPLAY remote control. In fact,
• the first remote control teaches the second
• one the correct code which is automatically
• saved in the receiver the first time it is used.
• Everything occurs at the highest levels of security
• thanks to the use of the Rolling Code safe transmission system.

Technical data sheets:

• Power consumption : 90 W
• Type of limit switch : Magnetic
• Protection rating : IP55
• Max. width of door/gate wing : 5 m
• Slowdown : Yes
• Environmental conditions : -20 ÷ 60 °C
• Max. weight of door/gate wing : 800 kg
• Locking : Selectable in opening/closing
• Interconnectivity : no
• Control unit : THALIA P
• Useful rod stroke : 392 mm
• Release : Triangle key
• Board power supply : 230 V
• Maximum angle : 110 °
• Impact reaction : D-Track
• Motor voltage : 24 V
• Cycle time : 20 s
• Frequency of use : very intensive
